Looking for Mellanox Transceiver compatibles? We have matched the Mellanox transceiver product portfolio with our transceivers below to assist you in building cost-effective networks with ease.

Mellanox Transceiver Compatibles

Our Mellanox compatible product line includes cost-efficient Mellanox 400G, 100G, QSFP+ SFP transceivers compatibles. We have carefully analyzed the product datasheets of Mellanox (Nvidia) LinkX 400G, 100G, QSFP+ SFP transceivers, and have mapped our products to the Part Numbers of Mellanox (Nvidia) LinkX OEM versions to make the work easier for data center engineers. Our compatible Mellanox modules are designed based on our own products, which can be seamlessly integrated with various Mellanox (Nvidia) datacenter equipment units such as routers, switches, and network interface cards.
We are offering a broad spectrum of compatible Mellanox optical transceivers, allowing engineers to achieve both cost benefits and the ability to build better network solutions, as our compatible transceiver portfolio can be considerably larger than that offered by manufacturers. Below you will find our list of Mellanox compatible transceivers ranging from 1G up to 400G data rates. If you have any questions, don’t hesitate to Contact Us!

Filter by Product categories
Mellanox

Mellanox 400G & 200G Transceivers

Mellanox 400G and Mellanox 200G compatible transceivers, enables one to build one of the fastest network connections nowadays. Such high speed connectivity is made possible by using cutting edge QSFP-DD sending 8x 50G PAM4 (Pulse-Amplitude Modulation) signals. These Mellanox 400G QSFP-DD and 200G Compatible modules are a good option for hyperscale data centers, internet exchanges, colocation services, wireless infrastructure core, service provider and operator core networks, and video distribution infrastructure because they enable connection establishment over distances of 100 meters to 10 kilometers. If your needs are a little less demanding, you might prefer the Mellanox 200G compatible modules, which are capable of 200GbE speeds thanks to the use of QSFP56 form factor and 4x 50G PAM4 (Pulse-Amplitude Modulation) signals. These 200G modules support distances of up to 2 kilometers.

Mellanox 100G QSFP28 Transceivers

Our compatible Mellanox 100G QSFP28 optical transceivers are designed for use in 100GbE Ethernet applications. The transceiver has selectable re-timing in both transmit and receive directions as well as it provides digital diagnostic monitoring of supply voltage, temperature, transmit/receive power, and laser bias. Our compatible Mellanox 100G QSFP28 transceivers use a fixed 103.25 Gbps data rate and are fully compliant with industry standards (QSFP28 MSA) and interoperable with other IEEE-compliant 100GBASE interfaces. Mellanox QSFP28 100G portfolio includes both traditional applications such as 100G SR4, PSM4, CWDM4, CLR4, LR4 and as well as newer applications such as 100G Single Lambda PAM4 DR. Additionally when there is a need to connect devices with different speeds our compatible 100G to 4x 25G converter can become handy.

Mellanox QSFP+ 40G Transceivers

Upgrade your data center and high-speed networking applications with cost-effective and high-performing Mellanox QSFP+ 40G compatible transceivers. Our Mellanox QSFP+ 40G compatible transceivers selection includes 40G SR (for multimode fiber interconnections up to 150m with MTP/MPO-12), 40G CSR (for multimode fiber interconnections up to 300m with MTP/MPO-12) and 40G LR (for singlemode fiber interconnections up to 10km with dual LC) transceivers. Additionally when there is a need to connect devices with different speeds our compatible 40G to 4x 10G Mellanox QSFP to SFP+ adapter can become handy.

Mellanox SFP28 25G Transceiver

Our Mellanox SFP28 25G Compatibles enable you to create connections by using the standard duplex connections over MMF for short distances or SMF for longer ones — typically for connecting remote sites. Our Mellanox SFP28 25G transceiver alternatives support the IEEE 802.3by 25G standard, but are also backwards compatible with SFP + ports meaning that our Mellanox 25G SFP28 Compatibles will operate at 10G speeds when plugged into SFP+ ports. Besides the standard SR and LR modules in our 25G portfolio we have BIDI 25G SFP28 transceivers and 25G solutions for applications such as CWDM, DWDM, Tunable and more. Employing our expertise, we are able to provide custom-tailored firmware and solutions for Mellanox 25G to most switches and network interface cards!

Mellanox 10G SFP+ Transceivers

Our Compatible Mellanox 10G SFP+ transceivers provide a cost-effective alternative of Mellanox OEM transceivers used in 10G Mellanox Ethernet NICs and switches. Mellanox 10GBE SFP+ modules have an IEEE 802.3ae compliant standard SFP+ interface on the electrical side towards the host system. The optical interface is composed of two optical channels/fibers, intended for connection of a suitable patch cord via a standard LC connector. In our compatible Mellanox 10G SFP+ modules section, you will find MMF (Multi Mode Fiber), SMF (Single Mode Fiber and RJ45 Cooper modules.

Mellanox SFP 1G Transceivers

Below we have covered our double fiber compatible Mellanox SFP modules for gigabit Ethernet transmission (SX) and Mellanox SFP 1G copper module. Additionally we can provide a full portfolio of 1G SFP transceivers (BIDI, CWDM, DWDM) which we can make compatible with Mellanox devices.
